Description
Leader in Inverter Welding
Specifications:
| Power Voltage (V) | Single Phase ACC220V±15% | ||
| Rated Input Current | 4KVA | ||
| No-load loss | 40W | ||
| Duty Cycle | 60% | ||
| Power Factor | 0.73 | ||
| Efficiency | 80% | ||
| Input Current | ARC | TIG | PLASMA |
| 34A | 26.4 | 34A | |
| Current Range | 10-160A | 10-160A | 20-40A |
| Open Circuit Voltage | 62V | 62V | 260V |
| Work Voltage | 15V | 25V | 92V |
| Inter - Diameter of Burner | - | - | Ø1 |
| Air Pressure (mpa) | - | - | 0.4MPa |
| Gas Flow Rate | - | 2-5L/min | 80L/min |
| Thickness | - | - | 12mm |
| Arc Initiating (TIG) | Touch | H-F | H-F |
6 Months Service Warranty
Inclusions:
Cutting Torch Assembly, Ground Clamp, Electrode Holder, Tig Torch Assembly
